Honeywell Vertex M
Honeywell Analytics Vertex M.
Provides a flexible 8 to 24 points of monitoring using the industry’s most reliable gas monitoring technology, colorimetric Chemcassette®.
Vertex M™ is an economical way to install, augment or upgrade a gas monitoring system for industries using toxic . It provides a flexible 8 to 24 points of monitoring for use with up to 3 Chemcassette analyzers or combination 1 pyrolyzer analyzer/1 universal Chemcassette analyzer; comes in a small, space-saving cabinet; 110V or 220V power options; and uses the industry’s most reliable toxic gas monitoring technology, colorimetric Chemcassette, which shows proof of a gas response through a telltale stain on the Chemcassette tape. The Vertex M integrates easily into a factory automation system or HMI to serve semiconductor, PV, nano, specialty chemical, lab and other High Tech/Industrial environments.
Cost Effective
- -Extended tapes (90 days) provides longer monitoring life
- -No calibration or flow balancing required
- -Additional pump and internal power module increase uptime
- -Software can be configured with out taking unit offline
- -Sampling points can be up to 400 feet (121m) from the monitor and routed to more than one analyzer.
Easy to use
- -Touch screen for easy access to data
- -Software updates via CD-ROM or network to all system components
- -Configuration profile editing and data retrieval are all achievable without taking unit offline
- -Radio frequency identification tag (RFID) ensures Chemcassettes® are installed into appropriately programmed analyzer, eliminating human error
- -On-line help system
Security
- -Multiple levels of password protection
- -Reconfigure security setup without taking unit offline
- -Low cost of ownership
- -Small footprint and greater density of points reduce your cost per point
- -Eight points per analyzer lowers Chemcassette® costs
- -Maximized 24 point systems provide low cost per point as compared to other continuous monitors
- -One system monitors up to three gas families and more than 40 gases
- -You can split your sample to more than one analyzer
Easy to maintain
- -Uses cost-effective XP Chemcassettes®, providing up to three months of continuous monitoring
- -Simplified replacement of Chemcassettes® and automated optics verification
- -No dynamic calibration required
- -No flow balancing
- -Easy access to analyzers, pumps, power supplies and touch screen from front panel
- -Onscreen interactive electronic manual
Advanced communications
- -Built-in configurable PLCs with optional 64 relay contacts
- -Standard OPC interface for easy integration into your existing factory automation system or HMI
- -Optional Ethernet/CIP, LONWORKS®, DeviceNetTM, DF1Interface, PROFIBUS, Modbus Plus, Modbus/TCP or ControlNet outputs available
