RAE Systems- MiniRAE 2000 Hand-held
VOC Monitor (0-10,000ppm).
The rugged MiniRAE 2000 is the smallest pumped handheld volatile organic compound (VOC) monitor on the market. Its Photoionization Detector’s (PID) extended range of 0-10,000 ppm makes it an ideal instrument for applications from environmental site surveying to HazMat/Homeland Security.
The MiniRAE 2000 detector can be made wireless with the use of RAELink2. This allows real-time monitoring information from the detector to be integrated into an existing AreaRAE system. A wireless, RF (radio frequency) modem allows detectors equipped with Firmware version 1.20 or higher to communicate and transmit readings and other information on a real-time basis with a remotely located AreaRAE base controller up to two miles away.
Applications:
Environmental
- Soil and water headspace analysis
- Leaking underground storage tanks
- Perimeter fence line monitoring
- Fugitive emissions (EPA Method 21)
- Vapor recovery breakthrough
- Landfill monitoring
HazMat/Homeland Security
- Initial PPE (personal protective equipment) assessment
- Leak detection
- Perimeter establishment and maintenance
- Spill delineation
- Decontamination
- Remediation
Industrial Hygiene/Safety
- Confined space entry
- Indoor Air Quality (IAQ)
- Worker exposure studies
Key Features:
- Proven PID technology: The patented 3D sensor provides 3 second response up to 10,000 ppm and sets a new standard for resistance to moisture and dirt.
- Self-Cleaning Lamp and Sensor: Our patented self-cleaning lamp and sensor minimize the need for maintenance and calibration.
- The MiniRAE 2000 lamp and sensor come apart in seconds for easy maintenance without any tools!
- Measure more chemicals than with any other PID: With over 100 Correction Factors built into the MiniRAE 2000’s memory and the largest printed list of Correction Factors in the world (300+), RAE Systems offers the ability to accurately measure more ionizable chemicals than any other PID! When a gas is selected from MiniRAE 2000’s library its alarm points are automatically loaded into the meter.
- 3-year 10.6 eV Lamp Warranty. Lifetime Instrument Warranty.
- Drop-in Battery: When work schedules require putting in more hours than the 10 hours supplied by the standard NiMH battery, the drop-in alkaline pack supplied with every MiniRAE 2000 lets you finish the job.
- User friendly screens make it easy to use for simple applications and flexible enough for sophisticated options.
- Rugged Rubber Boot: The standard rubber boot helps assure that the MiniRAE 2000 survives the bumps and knocks of tough field use.
- Strong, built-in sample pump draws up to 100 feet (30m) horizontally or vertically.
- Tough flexible inlet probe
- Large keys are operable even with 3 layers of gloves
- Easy-to-read display with backlight
- Stores up to 267 hours of data at one minute intervals for download to a PC (with the optional datalogging)
