Honeywell RAE Systems - AreaRAE Pro

$11,569.00
SKU
RAEW01A-1

AreaRAE Pro -

The AreaRAE Pro is a transportable multi-threat area monitor that simultaneously detects toxic and combustible gases, Volatile Organic Compounds (VOCs), radiation, and meteorological factors that affect the speed, direction and behavior of gas — for enhanced situational awareness. It works with Honeywell’s remote monitoring software, so you can see the realtime threat readings, alarm status, location of each AreaRAE Pro and much more — and make faster, more informed safety decisions. Whether you’re carrying the monitor into a hot zone, setting up a perimeter or deploying it at a public venue — for hours, days or weeks at a time — count on the AreaRAE Pro to give you the right hazard intelligence so you can ensure the safety of your teams and the general public.   The AreaRAE Pro sends gas, radiation, meteorological readings and location data to real-time monitoring software, so you can see the status of each monitor — plus other wireless gas detectors in your fleet — all in an easy-to-use, map-based display, accessible from any computer with an internet connection. That means you can instantly determine the location and severity of a threat, while coordinating joint operations and sharing data with other teams.   Choose seven sensors based on your needs, and switch them out whenever your needs change. Whether you’re monitoring for a Radiological attack at a public venue or entering a clandestine drug lab, you can select from more than 20 sensors for toxic gases, oxygen and multiple combustible gases at the lower explosive limit (LEL).

AreaRAE Plus Brochure

AreaRAE Plus Datasheet

AreaRAE Pro Supported Sensors

Specifications
Sensor Range Resolution
PID Sensor Options
4R+; 10.6eV ppb 0 to 2,000 ppm 10 ppb
7R+; 10.6 eV ppb 0 to 2,000 ppm 10 ppb
4R+; 9.8 eV 0 to 2,000 ppm 0.1 ppm

NDIR Sensor Options
Carbon Dioxide (CO2) 0 to 50,000 ppm 100 ppm

Combustible Sensor
Catalytic Bead  0 to 100% LEL 1% LEL

Electrochemical Sensors
Ammonia (NH3) 0 to 100 ppm 1 ppm
Carbon Monoxide (CO) 0 to 500 ppm 1 ppm
Carbon Monoxide Ext. (CO HR) 0 to 2,000 ppm 10 ppm
Carbon Monoxide H2 Comp (CO H2 Comp) 0 to 2,000 ppm 10 ppm
Chlorine (Cl2) 0 to 50 ppm 0.1 ppm
Chlorine Dioxide (ClO2) 0 to 1 ppm 0.03 ppm
Ethylene Oxide (ETO-A) 0 to 100 ppm 0.5 ppm
Ethylene Oxide (ETO-B) 0 to 10 ppm 0.1 ppm
Ethylene Oxide (ETO-C) 0 to 500 ppm 10 ppm
Hydrogen (H2) 0 to 2,000 ppm 10 ppm
Hydrogen Chloride (HCl) 0 to 15 ppm 1 ppm
Hydrogen Cyanide (HCN) 0 to 50 ppm 0.5 ppm
Hydrogen Flouride (HF)* 0.5 to 10 ppm 0.1 ppm
Hydrogen Sulfide (H2S) 0 to 100 ppm 0.1 ppm
Hydrogen Sulfide Ext. (H2S HR) 0 to 1,000 ppm 1 ppm
Oxygen (O2) 0 to 30 % 0.10 %
Sulfur Dioxide (SO2) 0 to 20 ppm 0.1 ppm
Nitric Oxide (NO) 0 to 250 ppm 0.5 ppm
Nitrogen Dioxide (NO2) 0 to 20 ppm 0.1 ppm
Phosphine (PH3) 0 to 20 ppm 0.1 ppm

Gamma Radiation Sensor
Gamma I-Sensor

0.01 μSv/h to 0.2 mSv/h
(1 μrem/h to 0.02 rem/h)

50 keV to 3 MeV



Meteorological Station (RAEMet) Option

Wind Speed Range: 0 to 20 m/s (0 to 44 mph) Start Speed: 0.1 m/s (0.22 mph)
Wind Direction Range: 360° (No dead band)
Temperature - 20 °C to 60 °C (-4 °F to 140 °F) Resolution 0.1 °C (1.8 °F)
Humidty 10 to 95% RH Resolution 1% RH
Compass Resolution 1°
Power Power supplied by the AreaRAE Pro

Features:

  • User-friendly interface; turn it on and go
  • Supports long-distance remote monitoring with the 900MHz radio (up to 2 miles)
  • Built-in 868MHz Mesh modem for short-range monitoring
  • Allows up to eight portable Mesh wireless instruments to connect (as a connection hub)
  • Monitors up to seven threats, including Gamma radiation, VOCs, combustibles, Toxics and Oxygen
  • Ppb performance level on VOC measurements
  • Local weatherstation
  • Ruggedized, portable and weather resistant design for harsh environments
  • Available in a Rapid Deployment Kit

Applications:

  • First Responders
  • Urban Search and Rescue
  • Hazmat
  • CBRN
  • Clandestine Labs
  • Fire Overhaul
  • Public Venue Protection
  • Civil Defense and Military
