Draeger PSS 5000 NFPA 2018 SCBA LP 2216psi w/ FPS 7000 Mask
Draeger PSS 5000 NFPA 2018 Edition SCBA Low Pressure 2216psi with FPS 7000 Mask -
The Draeger PSS® 5000 is effective firefighting requires trusted breathing protection in the harshest environments. The Draeger PSS® 5000 provides the budget-conscious fire department with an ergonomically advanced SCBA. With a wide range of features – such as bi-lateral hose routing and cylinder Quick Connection – the PSS® 5000 meets the needs for today's complex fire grounds.
The FPS 7000 full face mask sets new standards in terms of personal safety, protection and comfort. The popularity of the FPS 7000 SCBA mask is due to a large, unobstructed field of vision and a very comfortable and secure fit, while reducing or eliminating fogging during use. The FPS 7000 mask is available in three sizes and has a double-sealed body with triple-sealing edges to conform to the shape of the face. The mask comes in highly chemically resistant EPDM rubber with a hairnet that is designed to be donned and doffed quickly and easily.
Draeger PSS 5000 NFPA Specification Sheet:
Draeger PSS 5000 NFPA SCBA.
Draeger FPS 7000 Mask Specification Sheet:
Draeger FPS 7000 Mask.
| Weight w/ Empty 45 min Cylinder | 24.8 lbs. (11.25 kg.) |
| Input pressure (psi) | Low-pressure, 2216 |
| Nominal first stage output pressure (psi) | 108 |
| First stage output flow (L/min) | >1,000 |
| LDV output flow (L/min) | >500 |
| Whistle activation pressure (psi) | high-pressure, 510 |
| Whistle sound level (dBA) | >90 |
| ADSU main alarm (dBA) | >95 |
| Approvals | NFPA 1981 & 1982, 2018 Edition |
- LP = Low Pressure, 2216 PSI
- LDV = Lung Demand Valve
Proven technology combines comfort with performance -
The Draeger PSS 5000 SCBA is designed to withstand the high wear and tear that firefighters face daily – while providing an enhanced level of comfort and functionality. Made of tough chloroprene rubber material and Aramid-blend webbing, the PSS 5000 harness is ideally suited for extended wear and frequent use. The flexible harness connects to a lightweight, stable back plate, while the waist belt pivots to reduce pressure on the wearer.
Integrated systems reduce risk and increase versatility -
To minimize the risk of damage or snagging, the Dräger Sentinel 7000 electronic system and air-supply hoses are integrated into the backplate. To further streamline and reduce snag hazards, the lung-demand valve (LDV) and Draeger Sentinel hoses are routed over the shoulders. Conventional waist-mounted hoses can also be fitted to the carrying system, making the Draeger PSS 5000 one of the most versatile SCBA systems available.
Easy maintenance to lower cost of ownership -
The following features keep Dräger PSS 5000 downtime and maintenance costs to a minimum:
‒ Innovative slide-and-lock mechanism for fast and easy harness assembly and disassembly
‒ Harness detaches from the backplate without the use of tools
‒ First stage reducer snap-fit connection allows pneumatics to be fitted or removed quickly and easily
‒ Hose clips push in and out to allow swift removal of hoses from the harness pads for cleaning
‒ Chemical-resistant harness and waist belt design prevent excessive water absorption and reduce cleaning
and drying time
‒ Standard AA batteries, no manufacturer-required overhaul, and few replacement parts contribute to a lower
total cost of ownership over the life of the SCBA
Draeger Sentinel 7000—Real-time monitoring -
The Sentinel 7000 electronic monitoring system provides options to satisfy the needs of any fire department. Incorporating a centralized power supply and pressure sensor module within the backplate, the robust system combines maximum component protection with balanced weight distribution for reduced physical stress. Housed in impact-resistant, water- esistant casings, the Sentinel 7000 demonstrates excellent reliability on the fire ground.
An electronic gauge provides real-time monitoring of essential information, including:
‒ A personal alert safety system (PASS) device
‒ Intuitive push-button operation for ease of use
‒ Configurable settings to suit individual preferences
‒ Data logging for improved post-incident analysis
‒ Accurate, continuously updated digital display of pressure and time to EOSTI activation (time based on
‒ dynamic breathing rate)
‒ Battery status display
‒ 360° visual and audible alarms triggered when the PASS is activated
‒ Automatic self-tests and system tests
Draeger FPS® 7000 Head-up Display -
One of the many benefits of the FPS® 7000 full-face mask is the headup display (HUD) required by NFPA 1981. Always within the field of view the head-up display allows easy monitoring of the cylinder contents and battery status without any manual action by the wearer.
Draeger FPS® 7000 -
The Dräger FPS® 7000 full-face mask sets the standard in safety, visibility, and comfort. Triple-sealing, the FPS 7000 comes in nine sizes and three shapes of the inner mask to ensure maximum protection by adapting to different head and face shapes.
Draeger FPS®-COM 7000 -
The Draeger FPS®-COM 7000 provides standalone hands-free communication along with optional connection to tactical radios. Voiceactivated, the FPS-COM 7000 provides full-duplex communication on one of seven user-selected channels. Up to 10 users per channel can be connected without using a tactical radio, which is especially ideal for special operations like hazardous materials response teams.
